Amplification matched to the drivers
The crossover and amplifiers are designed for the drivers in each cabinet. The signal path is analogue, without DSP, and the built-in amplification removes the need for a separate power amplifier.
ACTIVE LOUDSPEAKER
PSI Audio A14-M Studio
A small two-way active speaker for desktop and close listening. It is the most compact choice in this range for enjoying music when the speakers sit within easy reach.
FromA$5,398 per pair
IS IT RIGHT FOR YOUR SYSTEM?
Why consider A14-M Studio?
For music at a desk, A14-M Studio keeps the speakers small and close to the listener. The exposed drivers suit a conventional desktop setup; Broadcast adds protection and installation features.
Measured individually in Switzerland
PSI Audio builds, measures and calibrates each speaker in Switzerland against its reference response. This sets up the speaker before it leaves the factory; placement and the room shape what you hear at home.
How does it compare?
Studio and Broadcast have the same published acoustic specifications. Studio has exposed drivers; Broadcast adds a metal grille and front level control for installation use. A17-M is the next step for deeper bass or a longer listening distance.
| Compare | A14-M Studio | A14-M Broadcast |
|---|---|---|
| Studio Red price | A$5,398 per pair | A$5,798 per pair |
| Design | Two-way active | Two-way active |
| Bandwidth at −6 dB | 56 Hz to 23 kHz | 56 Hz to 23 kHz |
| Each cabinet: W × H × D | 163 × 243 × 170 mm | 163 × 243 × 170 mm |
| Weight per cabinet | 4.9 kg | 4.9 kg |
| Manufacturer distance guide | 0.5 to 1 m | 0.5 to 1 m |
Allow extra space for cables, ventilation and stands. Listening distances are PSI’s setup guide.
A14-M Studio
Exposed drivers for a straightforward desktop or stand-mounted setup.
A14-M Broadcast
Metal grille, front level control and a bracket-mounting design for fixed installations. Ask us about brackets for your mounting position.
Connections and placement
DAC / preamplifierAnalogue output · volume controlled
Left output → XLRLeft speakerMains power to each cabinet
Right output → XLRRight speakerMains power to each cabinet
- Connect the left and right variable analogue outputs of your DAC or preamplifier to the speakers’ XLR inputs. A fixed-output DAC needs a preamplifier or volume controller between it and the speakers.
- The XLR input takes a line-level signal. Never connect a power amplifier’s speaker output to it. Start playback at low volume after connecting the system.
- A subwoofer needs a line-level feed that follows the main system volume. Set its level and crossover alongside the main speakers so they blend through the bass.
Where to place it
Raise the speakers towards ear height with suitable desktop supports and leave space behind them for XLR and power cables. A little distance from the desktop can help reduce nearby reflections.
Each cabinet needs mains power and ventilation around its amplifier panel. The manual covers voltage selection and installation clearances. Use the distance guide above as a starting point for your listening setup.
COLOURS & PRICES
Choose your finish.
The starting price is for Studio Red. Compare all three finishes below.
| Finish | Per pair | Each |
|---|---|---|
Studio RedProduct codeA14MSR | A$5,398 | A$2,699 |
Metal BlackProduct codeA14MSB | A$5,598 | A$2,799 |
Pure WhiteProduct codeA14MSW | A$5,598 | A$2,799 |
A pair contains two speakers, priced at twice the single-unit price.
Enquire about this model
Specifications
- System
- Two-way active
- Bandwidth at −6 dB
- 56 Hz to 23 kHz
- Typical listening distance
- 0.5 to 1 m
- Peak maximum SPL at 1 m
- 113 dB, manufacturer product page
- Amplifier peak power (manufacturer)
- 110 + 45 W
- Dimensions (W × H × D)
- 163 × 243 × 170 mm
- Net weight
- 4.9 kg
- Inputs
- 1 × balanced XLR, female 3-pin
SPL is the manufacturer’s peak figure at 1 m. Amplifier power is also a peak rating; neither figure describes continuous output.
Technical documents
Common questions
Can I keep my current amplifier or source?
Yes, if it provides an analogue output with volume control. A DAC with variable XLR outputs can connect directly; a fixed-output DAC needs a preamplifier. An integrated amplifier with a variable pre-out can also serve as the front end. For RCA outputs, use a cable wired for the PSI input.
Do I also need a subwoofer?
You can start with the main speakers on their own. Add a subwoofer if you want more of the lowest bass in your music or films. Its position, volume and crossover need to work with the main speakers.
What warranty does PSI Audio provide?
PSI Audio provides a five-year warranty, with an extra year when you register your product.
